Kordz ONE Series CAT 6A F/UTP Cable
Product Information
Product Documents
Product Outline
Kordz ONE Series CAT 6A F/UTP premium cable is engineered to exceed 4K video installation bandwidth requirements and minimize alien crosstalk or electromagnetic interference in complex systems. The Rapid-EZ reel is meter marked and flows from the supplied professional pull box without twisting or curling, minimizing snags for optimal installation uptime. ONE series CAT 6A F/UTP cable is tested and approved to exceed 550Mhz, ANSI/TIA 568-C.2 and ISO/IEC 61156-5 standards.
- Suitable for 10BASE-T, 100BASE-TX, 1000BASE-T/1000BASE-TX (Gigabit) & 10GBaseT, PoE & PoE+
- F/UTP Ethernet CAT6a
- Four Twisted Pairs 23 AWG Solid Copper Conductors
- PVC Separator Reduces Crosstalk Between Pairs
- Mylar laminated aluminum tape shielding with a 26AWG drain wire
- Suitable for IDC Terminations
- Supplied in the durable Rapid-EZ-Reel packaging â 152.5m (500ft)
- Meter Marked
- 5 colors available: Blue, Green, White, Yellow & Purple
- Exceeds ANSI/TIA 568-C.2 and ISO/IEC 61156-5 standards
- Available in LSZH â IEC60332-3-25 and UL 444 CM fire rated versions
- CPR Declared Performance: ONE-CAT6A: Dca-s1, d2, a1 (EN 50575:2014+A1:2016)
CONSTRUCTION
Conductor:Â Solid OFC annealed bare copper wire 0.561 +0/-0.015mm [23AWG]
Insulation: Orange & Brown Pairs â Polyethylene (PE), 1.12+/-0.05 mm Blue & Green Pairs â Foam PE, 0.97 +/-0.05 mm
Twisting:Â 4 twisted pairs, 2 cores to each pair
Twisted Pair Color Code: 1 â white-blue/blue, 2 â white-orange/orange, 3 â white-green/green, 4 â white-brown/brown
Cable Lay-Up:Â 4 pairs with different pitches, non-metallic cross separator (spine)
Shielding: Drain wire [26AWG], Mylar tape laminated with aluminum foil as a shield
Outer Diameter:Â 7.4 +/-0.3 mm
MECHANICAL
Bend Radius:Â without load â„ 29.6mm /1.16â, with load â„ 59.2mm /2.33â
Temperature Range: During Operation: -20°C to 60ÂșC During Installation: 0°C to 50ÂșC
ELECTRICAL
DC Resistance: †9.38Ω / 100m at 20ÂșC
Resistance Unbalance: †2% at 20ÂșC
Insulation Resistance (500V): ℠5000MΩ / km at 20ÂșC
Mutual Capacitance: †5.1 nf / 100m at 1khz
Capacitance Unbalance (pair to ground): †160 pf / 100m at 1khz
Nominal Velocity of Propagation:Â nom. 67% c
Test Voltage:Â 1kV DC / 1 min
MATERIALS/MARKING & FIRE RATINGS
LSZH
Kordz ONE Solid OFC UHD/4K Video Network Cable. ETL VERIFIED TIA-568-C.2 (100372289CRT-001c) LSZH CAT6A F/UTP 23AWG. IEC 60332-3-25
FRPVC
Kordz ONE Solid OFC UHD/4K Video Network Cable. ETL VERIFIED TIA-568-C.2 (100709714CRT-002c) CM CAT6A F/UTP 23AWG. UL 444 CM
PACKAGING
Size: 152.5m / 500ft or 305m / 1000ft spool â meter marked and
Carton Dimensions:Â 330mm (W) x 265mm (D) x 340mm (H) / 13.0in (W) x 10.4in (D) x 13.4in (H)
Volume:Â 0.03m2 / 1.05 cu. ft.
Gross Weight: 9.8kg / 21.6lbs
