XTREME POWER CONVERSION Li90 10kW-30kW

10kW, 20kW, and 30kW | 208/120VAC Three-Phase | Compact. Powerful. Lithium Safe

Advanced Lithium UPS for Demanding Environments

The Li90 is a compact, high-performance 208V three-phase online UPS that uses advanced Lithium Iron Phosphate (LiFePO₄) batteries, delivering up to three times the life of traditional VRLA systems. Its narrow footprint makes it ideal for tight installations in industrial, edge, and IT environments.
Designed for demanding applications, the Li90 provides clean, reliable power in high-temperature conditions up to 50°C. Hot-swappable battery modules allow maintenance without downtime, and it’s backed by a 5-year battery warranty and 2-year on-site UPS warranty—offering long-term reliability with lower maintenance costs.

PRODUCT SNAPSHOT

Available models: 10kW, 20kW, 30kW
› Unity power factor
› Lithium Iron Phosphate Battery Modules
› Approvals: UL1778, UL38.3, UL1973
› Startup and 2 Year on-site warranty (USA and Canada)
› 5 year battery warranty (USA and Canada)

FEATURES

• Long-Life LiFePO₄ Batteries — Up to 10 years of service life and 2,000+ charge cycles
• Hot Swappable Battery Modules —Fast replacement with no system downtime
• Slim Cabinet Design — Just 12.6” wide—ideal for edge, automation, and retrofit installations
• Touchscreen LCD Interface — 4.3” full-color display with single-line mimic and event logging
• High Overload Capacity — 110% for 60 minutes, 150% for 1 minute—built for surges and startup loads
• Maintenance Bypass —Integrated bypass allows safe, on-site service without shutdown
• Smart De-Dust Fans — Self-cleaning fans help extend service life
• Conformal Coated PCBs —Enhanced protection in industrial and high-humidity environments
• Flexible Input Options —Supports single or dual input (rectifier & bypass); pre-installed jumpers included
• Advanced Communication —2 card slots, RS485, USB, EPO, 1 input & 5 output dry contacts; optional SNMP
